Featured Pneumatic Demolition Hammers & Drills
Explore our high-performance air demolition picks and pneumatic drills optimized for rock breaking, quarrying, and secondary demolition.
The Role of Pneumatic Demolition Hammers in Modern Quarrying
Understanding market dynamics, operational challenges, and technical innovations driving high-efficiency rock breaking equipment.
Quarry operations worldwide require robust, continuous, and high-impact rock extraction equipment capable of withstanding severe physical demands. Among the most essential hand-held equipment in aggregate, marble, granite, and limestone extractions is the Pneumatic Demolition Hammer for Quarry applications. Unlike lighter municipal breakers, quarry-grade pneumatic hammers are specifically engineered to crack, split, and reduce dense geological strata with high compressive strength.
High Percussive Impact Energy
Designed with large-bore pistons and optimized valve cycles to deliver intense percussive foot-pounds of energy required to fracture hard granite, basalt, and silica rocks efficiently.
Forged Alloy Resilience
Manufactured using drop-forged alloy steel housings subjected to deep carburizing and vacuum quenching, preventing structural fatigue in abrasive dust environments.
Optimized Air Economy
Advanced pneumatic airflow pathways maximize impact frequencies (BPM) while minimizing total compressed air consumption, reducing overall diesel generator operating costs.
Global Market Evolution & Strategic Trends in Quarrying
The global quarrying and mining sector is undergoing a rapid transition toward enhanced operational efficiency, strict safety compliance, and reduced environmental footprint. Pneumatic demolition tools have adapted to these trends through key design evolutions:
- Vibration Reduction Technologies (VRT): Modern pneumatic hammers incorporate internal damper springs and air-cushioned stroke returns, substantially lessening operator fatigue and preventing long-term physical strain during multi-shift quarrying operations.
- Enhanced Dust Suppression Compatibility: With increasing international regulations regarding occupational silica dust exposure, contemporary rock breakers feature optional integrated water mist attachment points or vacuum suction shrouds.
- Interchangeable Tooling & Standardized Shanks: Operators prefer tools like the TS11, TPB-40, and B47 series that utilize standard shank dimensions (such as R22, R25, or R32), allowing rapid swapping between points, chisels, and wedge cutters.
- Low-Maintenance Pneumatic Valve Systems: Tubular and dynamic shuttle valve systems reduce internal moving parts, rendering tools less sensitive to minor air-line moisture or ambient temperature fluctuations.
Deep Breakdown: Where Pneumatic Demolition Hammers Excel
From dimensional stone extraction to secondary boulder reduction, pneumatic tools deliver surgical precision where heavy excavators cannot operate.
Secondary Boulder Splitting & Reduction
After primary explosive blasting or large hydraulic hammer excavation, massive oversized rock boulders often block quarry crusher hoppers. Handheld pneumatic demolition hammers allow operators to break these boulders on site efficiently without re-blasting, ensuring continuous plant feed and preventing crusher jams.
Bench Trimming & Highwall Clearance
Maintaining safety along quarry benches and highwalls is critical. Pneumatic rock breakers are lightweight enough for rope-access operators to scale vertical rock faces, loosening fractured rock overhangs and trimming unstable loose strata to prevent dangerous rockfalls.
Dimensional Stone Quarrying (Marble & Granite)
In high-value marble, granite, and sandstone quarries, explosive blasting is avoided to prevent micro-fracturing inside valuable blocks. Pneumatic hammers fitted with wedge chisels are used to split quarry blocks cleanly along natural bedding planes, preserving stone integrity for export.
Trenching, Sumps & Quarry Drainage Infrastructure
Quarries require extensive water management sumps and drainage ditches to handle runoff water. Compact air breakers like the TS11 and TCD-20 enable precise trenching through solid rock floors where heavy excavators lack maneuverability.
TS11 Pneumatic Breaker & Air Pick Technical Profile
Light-duty yet heavy-impact jack hammer designed for quarry rock breaking, mining trimming, and municipal applications.
SHENLI TS11 Pneumatic Air Pick
The SHENLI TS11 pneumatic pick is a professional light-duty pneumatic breaker with performance metrics comparable to the classic TCD20 model. Designed specifically for quarry rock breaking, trimming, and mining assist work, this jack hammer delivers reliable impact energy with minimal total cost of ownership (TCO).
We solve major overseas customer pain points regarding spare parts shortages. We maintain a full inventory of original accessories—including chisels, pistons, valve assemblies, return springs, sealing rings, and positioning pins—ready for instant worldwide dispatch.
- Forged Alloy Body: Resists severe abrasion and impact shock.
- Standardized Accessories: Single parts or complete wearing sets available without minimum order limits.
- High BPM Output: 1630 Blows Per Minute for rapid rock fracture.
Main Parameters of Air Pick & Pneumatic Demolition Hammer Series
| Parameter / Model Name | TCA-7 | TCD-20 | TS11 | TPB-40 | TPB-60 | TPB-90 |
|---|---|---|---|---|---|---|
| Piston Diameter | 35 mm | 42.85 mm | 38 mm | 44 mm | 57.15 mm | 66.67 mm |
| Piston Stroke | 120 mm | 60 mm | 135 mm | 146 mm | 100 mm | 152 mm |
| Percussive Frequency (B.P.M) | 1250 BPM | 2000 BPM | 1630 BPM | 1050 BPM | 1400 BPM | 1400 BPM |
| Net Weight (N.W) | 7.2 kg | 10 kg | 10.1 kg | 18 kg | 30 kg | 42 kg |
| Total Tool Length | 465 mm | 520 mm | 600 mm | 660 mm | 645 mm | 723 mm |
| Air Consumption | 1.0 m³/min | 1.1 m³/min | 19 L/S | 1.6 m³/min | 2.0 m³/min | 2.2 m³/min |
| Tracheal / Hose Diameter | 19 mm | 19 mm | Inlet 12 mm | 19 mm | 19 mm | 19 mm |
| Bit Head Shank Size | R26*80 | R26*80 | R22*82.5 | R25*108 | R32*152 | R32*152 |
Company Profile & Global Footprint
SHENLI: Over 18 years of precision engineering in pneumatic rock breaking technology.
SHENLI is a leading manufacturer and supplier of superior pneumatic tools for the construction, mining, and quarry markets worldwide. Since 2005, the SHENLI brand has been synonymous with uncompromised quality, durability, and innovation.
For nearly two decades, the SHENLI brand has represented high performance in the pneumatic tool industry. The SHENLI product line now encompasses a complete range of pneumatic rock drills, paving breakers, air picks, and high-strength accessories produced in our wholly-owned precision factory.
With direct factory seller pricing, ergonomically refined tool balance, robust quality warranties, and dedicated technical support, SHENLI has established itself as an international industry leader. Choosing SHENLI means gaining a long-term engineering partner commitment from consultation to site delivery.
Company Mission & Vision
Striving to be a world-class supplier of rock drills and pneumatic demolition tools.
Adhering to decades of specialized manufacturing experience, SHENLI takes "customer first, service first" as our core spirit. We continuously innovate technology, strive for zero-defect production, and empower global quarry operators to achieve higher productivity.
State-of-the-Art Factory Tour & Production Lines
Precision manufacturing from raw material selection to automated assembly and percussive testing.
Advanced Manufacturing Stages
- Raw Materials: All alloy steel stock is sourced from leading domestic and international steel mills to guarantee zero internal material flaws.
- Precision CNC Machining: Multi-axis CNC lathes and milling machines ensure tight dimensional tolerances on pistons, cylinders, and valve boxes.
- Sealed Heat Treatment: Controlled-atmosphere quench furnaces carry out carburizing, nitriding, quenching, and tempering for high fatigue resistance.
- Micron-Grinding Line: World-class CNC grinding equipment maintains precision fits down to 3 microns on critical sliding components.
- Surface Protection: Electrostatic painting and anti-corrosion treatments prolong tool life under wet quarry conditions.
- Assembly & Testing: Every rock breaker undergoes bench testing for torque, BPM, and air consumption before receiving a quality certificate.
Rigorous Quality Assurance & International Certifications
Certified compliance ensuring safety, efficiency, and seamless trade within global markets.
Zero-Defect Quality Policy
SHENLI operates strictly under the ISO 9001:2015 Quality Management System standard. Experienced quality inspectors utilize high-precision gauges, coordinate measuring machines (CMM), and functional test rigs to audit every single component.
- Customer satisfaction achieved through zero-defect products and on-time delivery.
- Continuous technology upgrades to maintain maximum production efficiency.
- Regular workforce skill training and process auditing.
- Full CE mark compliance for free distribution in the European Economic Area (EEA).
International Quality & IP Certificates
ISO 9001:2015 Certified
CE Marking: Air Picks
CE Marking: Rock Drills
IP & Patent Certificate
Global Client Success Stories in Quarrying & Demolition
Trusted by contractors and quarry mine operators across Europe, the Americas, Asia, and India.
Dutch Client Custom Order (500 Units)
The Dutch delegation inspected our precision CNC workshop and heat treatment facility. Highly satisfied with our manufacturing equipment and quality assurance processes, the client signed a custom contract for 500 units of pneumatic demolition breakers for European civil engineering projects.
U.S. Client Strategic Partnership
American mining equipment distributors visited our production headquarters for in-depth negotiations regarding North American distribution. The meeting culminated in a long-term supply agreement for heavy-duty quarry rock drills and air picks.
Japanese Engineering Collaboration
Japanese clients reviewed our micro-grinding capabilities and dimensional inspection procedures. IMPRESSED by our 3-micron tolerances, they initiated a co-design partnership for customized light-weight demolition tools.
Indian Quarry Operator Supply Agreement
Indian quarry representatives inspected our ISO 9001-certified assembly lines to understand component durability under heavy granite quarrying conditions. The meeting resulted in a recurring procurement partnership for rock drill rods and air picks.
Maximizing Lifespan & Performance in Quarries
Essential operational guidelines to prevent premature piston wear and reduce spare part consumption.
Continuous Air Lubrication
Always utilize an in-line automatic lubricator filled with pneumatic tool oil. Operating a quarry demolition hammer without proper oiling leads to thermal cylinder scoring within hours.
Air Dryer & Moisture Traps
Quarry air lines often accumulate water condensation. Installing moisture separators at the compressor output prevents internal valve rusting and hydraulic locking.
Chisel Bushing Monitoring
Check shank tolerances weekly. Worn front bushings allow the chisel to tilt excessively, causing off-center piston impacts that can fracture internal hammer cylinders.
