Featured Mining & Pneumatic Machinery
South African Mining Sector & Rock Drilling Demand
Pioneering Hard Rock Extraction in Extreme Geological Formations
South Africa stands as one of the world's most mineral-rich nations, boasting immense reserves of Platinum Group Metals (PGMs), gold, manganese, iron ore, and chrome. Operating across premier geological hubs such as the Bushveld Igneous Complex, the Witwatersrand Basin, and the rugged manganese fields of the Northern Cape requires specialized pneumatic drilling machinery capable of enduring ultra-deep narrow-reef stoping, severe ambient temperatures, and abrasive quartzites.
In narrow-reef underground mines—where seams measure under 1.2 meters in height—large automated drill rigs cannot navigate the restricted geometries. As a premier manufacturer and supplier, Shenli provides the YT24 Air-Leg Rock Drill, engineered specifically to excel in challenging stoping, box-hole drilling, raising, and developmental tunneling operations throughout South Africa.
Bushveld Platinum & Chrome
High penetration rates in chromite layers and pyroxenite reefs around Rustenburg, Steelpoort, and Polokwane.
Witwatersrand Deep Gold
Resilience against high compressive stress and extreme ambient heat in ultra-deep level stoping.
Why the South African Mining Industry Relies on Shenli YT24 Jackleg Drills
The Shenli YT24 Air-Leg Rock Drill incorporates state-of-the-art grouped valve controls, rapid back-head flushing mechanics, and an optimized power-to-weight ratio. It integrates seamlessly with FT160BD or FT160A pneumatic pusher legs, offering exceptional torque and blow energy to drill horizontal, inclined, and blast holes through hard rock formations ranging from Protodyakonov hardness scale f=8 to f=18.
Shenli YT24 Technical Innovations & Performance
High Energy Impact & Speed
Equipped with a precision-forged cylinder and optimized piston stroke mechanism, the YT24 provides over 65 Joules of percussive impact energy, ensuring ultra-fast penetration in tough granite, iron ore, and dolomite reefs while minimizing operator fatigue.
Strong Air-Water Flushing
Features an integrated central water flushing system that effectively clears sludge and stone chips from the blast hole, suppresses harmful airborne silica dust, and preserves bit sharpness for prolonged drilling cycles.
Wear-Resistant Alloy Steel
Critical components undergo specialized carburizing, vacuum nitriding, and sealed-quench heat treatments to withstand intense frictional wear, high pneumatic pressures, and corrosive mine water conditions.
Working Application Scenarios
1. Municipal Road Maintenance Works
Used for breaking damaged asphalt roads, cracked concrete pavement, old road curbs and road base residues. It is the main tool for daily road rush repair and road renovation projects, fast breaking and high efficiency.
2. Building Renovation & Demolition Works
Suitable for indoor and outdoor partial demolition of old buildings, breaking concrete walls, floor slabs and building foundations. Flexible operation in narrow spaces where large machinery cannot work.
3. Open-pit Mining & Quarry Works
Used for trimming rock faces, breaking loose ore blocks, cleaning piled rock waste and secondary crushing of large rocks, ensuring smooth mining operation.
4. Tunnel & Civil Engineering Works
Auxiliary breaking and trimming inside the tunnel, removing protruding rock bodies and construction waste to keep tunnel surfaces flat and ensure construction safety.
TS11 Pneumatic Breaker Light Duty Mining Jack Hammer
Product Overview & Core Capabilities
SHENLI TS11 pneumatic pick is a professional light duty pneumatic breaker with application range similar to TCD20. Designed mainly for mining and quarry rock breaking this jack hammer delivers stable performance and lower operation costs with complete spare parts support and flexible packaging options.
We solve the core overseas customer concern of spare parts shortage and delayed replacement. We provide full set original accessories for this pneumatic breaker including chisels pistons valve assemblies return springs sealing rings and positioning pins. All wearing parts are sufficiently stocked all year round.
All accessories adopt unified standard specifications with strong universality and interchangeability. Customers can purchase single parts or complete wearing part sets without minimum order limit for accessories. Fast independent accessory delivery ensures quick on site equipment maintenance and avoids construction shutdown losses.
Engineered for Heavy Demolition
The TS11 Pneumatic Pick is a robust handheld air demolition tool engineered for heavy-load breaking jobs. Widely adopted in construction, mining and road maintenance sectors, this air pick delivers powerful impact force with stable pneumatic performance.
Built with high-strength alloy steel body, TS11 pneumatic pick resists wear under continuous working conditions. Compact body design allows easy operation in narrow working spaces. It is compatible with standard pneumatic chisels, easy for daily maintenance and spare-part replacement.
Key Engineering Features:
- High impact power, efficient for concrete, rock, asphalt breaking
- Heavy-duty alloy housing, long service life
- Stable air power output, low failure rate
- Light-weight handheld structure, convenient field operation
- Easy disassembly, simple maintenance
Specialized Application Scenarios
Building Renovation and Partial Demolition
This pneumatic demolition hammer fits partial building demolition tasks. It breaks concrete walls floor slabs and building foundations in indoor and outdoor environments. Compact body allows flexible operation in narrow spaces where large machinery cannot reach.
Tunnel and Civil Engineering Construction
This air breaker provides auxiliary breaking and trimming for tunnel working faces. It removes protruding rock bodies and construction waste to keep tunnel surfaces flat and ensure construction safety.
Infrastructure Reconstruction Projects
This pneumatic pick supports bridge renovation foundation dismantling and municipal partial breaking work. It maintains stable performance under complex site conditions.
Main Parameters of Air Pick & Pneumatic Breaker Products
| Parameter / Name | TCA-7 | TCD-20 | TS11 | TPB-40 | TPB-60 | TPB-90 |
|---|---|---|---|---|---|---|
| Piston Diameter | 35mm | 42.85mm | 38mm | 44mm | 57.15mm | 66.67mm |
| Piston Stroke | 120mm | 60mm | 135mm | 146mm | 100mm | 152mm |
| Percussive Frequency | 1250 B.P.M | 2000 B.P.M | 1630 B.P.M | 1050 B.P.M | 1400 B.P.M | 1400 B.P.M |
| Net Weight (N.W) | 7.2kg | 10kg | 10.1kg | 18kg | 30kg | 42kg |
| Overall Length | 465mm | 520mm | 600mm | 660mm | 645mm | 723mm |
| Air Consumption | 1.0 m³/min | 1.1 m³/min | 19 L/S | 1.6 m³/min | 2.0 m³/min | 2.2 m³/min |
| Tracheal Diameter | 19mm | 19mm | Inlet 12mm | 19mm | 19mm | 19mm |
| Bit Head Size | R26*80 | R26*80 | R22*82.5 | R25*108 | R32*152 | R32*152 |
Company Profile & Corporate Culture
SHENLI is a leading supplier of superior pneumatic tools for the construction, mining and industrial markets. Since 2005, the Shenli brand has been synonymous with quality and innovation.
For over a decade, the SHENLI brand has represented performance, innovation and quality in the pneumatic tool industry. The SHENLI product line now offers a complete line of pneumatic tools, a wholly owned factory, pneumatic tools and a full line of accessories. With superior product performance, as well as superior product and reliability, competitive pricing for factory direct sellers, exceptionally ergonomically designed tools and quality warranty terms, Shenli has become an industry leader. We take every customer's problem seriously so that we can solve our common problems, and choosing Shenli is just the beginning for you. SHENLI will provide reliable service and support through every step of the process from product consultation to final delivery.
Striving to be a world-class supplier of rock drill: Adhering to the development experience of pneumatic tools for many years, Shenli takes "customer first, service first" as the spirit of enterprise, and "strive to become the world's first-class rock drill provider" as the vision, constantly innovate technology, strive for perfection, and open up a broader market for customers.
Company Mission & Corporate Culture
More Attentive: Work together, keep improving.
More Focused: With sincerity, you can achieve anything.
More Thoughtful: Customer first, service first.
Dare to Innovate: Keeping up with the times and forging ahead.
Factory Tour & Production Workshop
1. Raw Materials
All materials are sourced from domestic and international well-known suppliers, and the quality is free from any flaws.
2. Precision CNC Machining
We have all precision machining production lines, including high-precision CNC lathes, and multi-axis CNC milling machines. Machine tools are from well-known brands, and online quality assurance is performed at every step.
3. Sealed Quench Heat Treatment
All heat treatment activities are carried out in a sealed quench furnace with facilities including but not limited to carburizing, nitriding, volume quenching, annealing, and tempering.
4. Micron Grinding Precision
We have world-class grinding equipment that is capable of maintaining dimensions to within 3 microns. The grinding line includes state-of-the-art equipment including universal CNC grinding machines, cylindrical CNC grinding machines with process gauges, CNC internal diameter grinding machines, and universal CNC grinding machines.
5. Surface Treatment
We offer a range of surface treatment options painting and other processes. These processes increase the service life of the tools and provide them with an appearance that meets the customer's requirements.
6. Assembly & Commissioning
Assembly and testing are carried out by our dedicated team on custom-built assembly platforms and test machines. Each assembled rock drill is tested for torque, BPM, and air consumption. After successful testing, each machine receives a test certificate to ensure its quality.
Quality Control & International Certifications
Zero-Defect Quality Standards
- Customer Satisfaction: Customer satisfaction is achieved through the provision of 'zero defect' products and timely delivery.
- Orderly Programme: Ensuring an orderly programme across all manufacturing phases.
- High Efficiency: Increased production efficiency through the latest technology and equipment.
- Continuous Training: The company provides regular training to its employees in accordance with the defined objectives, training needs and requirements.
Shenli is ISO 9001:2015 certified. We strive to constantly monitor and improve our processes to ensure the highest quality products. Experienced quality inspectors use a variety of precision instruments and special gauges to test the dimensional and functional performance of all components. Regular internal and external quality audits are carried out to continuously improve quality.
CE certification is a mandatory conformity mark for certain products sold within the European Economic Area (EEA). CE stands for "Conformité Européenne" which translates to "European Conformity." The CE mark certifies that a product has met EU consumer safety, health or environmental requirements. CE certification also allows manufacturers to freely circulate their products within the EEA. ISO 9001:2015 is an international quality management system (QMS) standard that outlines requirements for a quality management system. The standard is designed to help organizations ensure they meet customer and regulatory requirements. Our factory has been ISO 9001:2015 certified since 2015, and all of our products are CE certified. This ensures that our products meet high standards of quality and safety, and that they can be freely circulated within the EU. CE certification and ISO 9001:2015 certification are just two of the ways we ensure that our products are of the highest quality.
ISO 9001:2015
ISO Management
CE Air Picks
CE Rock Drills
Epiroc Intellectual Property Certificate
Global Client Case Studies & Cooperation
Dutch Clients (Netherlands)
The Dutch customer came to our factory and was satisfied with the production equipment, raw materials as well as advanced processes that we have in place. The client then signed a custom order for 500 units after being shown all of these great things about what is possible here at this facility! They hope long-term cooperation can occur between both parties moving forward since they are happy overall from their visit today.
U.S. Customers (United States)
The American customer visits our factory and has an in-depth negotiation to reach a long-term cooperation relationship.
Japanese Customers (Japan)
The Japanese customer was very satisfied with the factory equipment and production process. He also proposed that they work together on design, which would give them an edge over their competitors who do not have this partnership!
India Customers (India)
We are delighted that Indian customers have visited our factory to learn more about ISO 9001 certification, which opens up new opportunities for us to collaborate. We explained in detail which parts go to which products, and how many different assembly lines there are, and we all understood. He is looking forward to working with us. This is our first cooperation, and we still maintain a cooperative relationship.
All Mining & Pneumatic Rock Drilling Products
